Rooftop Mounted Wall Split Single Fan RV AC Unit
Enjoy a cool summer in the comfort of your RV!
Safety
The software and hardware have undergone international standard vibration testing, aging testing, and durability testing to ensure long-term safe use for users.
Energy Saving
Intelligent energy-saving technology, low power consumption, long battery life, reduced energy loss, and protection of the battery from current surges.
Lightweight
Wall mount rv ac unit lightweight equipment, lower energy consumption, and more space on the roof for installing solar panels and other devices.
Product specification
Get comprehensive data on this Rv Rooftop Ac Unit ➔
| Model: | K12TX-727 | K24TX-323 | K48TX-727 |
| Rated input voltage: | 12V DC | 24V DC | 48V DC |
| Rated input current: | 75A | 30.5A | 18.75A |
| Rated input power: | 900W | 732W | 900W |
| Rated cooling capacity: | 9300BTU | 7900BTU | 9300BTU |
| Temp Range: | 17-30°C | 17-30°C | 17-30°C |
| Refrigerant type: | R407C | R134a | R407C |
| Weight of outdoor unit: | 19.5kg | 19.5kg | 19.5kg |
| Weight of indoor unit: | 7.0kg | 7.0kg | 7.0kg |
| Indoor unit can be selected: |  | ||
| Model: | K12TS-322 | K12TS-725 | K24TS-322 |
| Rated input voltage: | 12V DC | 12V DC | 24V DC |
| Rated input current: | 60A | 77A | 30A |
| Rated input power: | 720W | 924W | 720W |
| Rated cooling capacity: | 7600BTU | 8600 BTU | 7600 BTU |
| Temp Range: | 17°C-30°C | 17°C-30°C | 17°C-30°C |
| Refrigerant type: | R134a | R407C | R134a |
| Weight of outdoor unit: | 19.5kg | 19.5kg | 19.5kg |
| Weight of indoor unit: | 6.0kg | 6.0kg | 6.0kg |
About
Break through
Independently developed split ac unit for rv intelligent control module and energy-saving twin-rotor compressor, low oil consumption, high air volume. Driving and parking operation capabilities, able to adapt to various bumpy, harsh weather conditions, and complex road conditions.
Indoor Unit
- High-grade UV-resistant material, remains unchanged in shape and color even after long-term exposure.
- Equipped with dual drain pipes for quick drainage of accumulated water during the rainy season.
- Independent multi-outlet design for efficient airflow and temperature control in different areas.
Cooling Pipes
- High-strength flexible pipes, resistant to aging and vibration.
- Customized pipe routing and length for different vehicle models, fully installed.
Outdoor Unit
- Tray-style design, compact size, low profile, easy to install and remove without increasing vehicle height.
- High water immersion resistance, capable of withstanding immersion in 1 meter of water for up to 30 minutes.
- Self-developed variable-frequency intelligent energy-saving module, minimizing energy loss during variable-frequency operation for ultra-high efficiency.
Frequently asked questions
What are the power requirements for an RV air conditioning system?
Unlike home air-conditioning, RV air-conditioning systems have unique power supply requirements, such as adequate power kilowatts, voltage, and current, controllable power management, intelligent energy-saving control functions, additional power support equipment, regular maintenance and monitoring mechanisms, and a safe grounding safeguard, all of which must be strictly followed and carefully verified for the sake of travel freedom and comfort.
Can a regular home air conditioner replace an RV air conditioner?
RV air conditioners are designed for mobile travel or living in RVs, whereas ordinary home air conditioners are designed for people living at home. Although both are add ac refrigerant temperature control products, the application scenarios are different, as are the product characteristics, and they cannot be used interchangeably. Specific differences include installation location, seismic rating, adaptability of power supply, product design, volume size, temperature weathering, energy efficiency, environmental standards, ventilation and drainage systems, temperature control, comfort, maintenance and after-sales service, price, and cost-effectiveness. Overall, caravan air conditioners are designed to offer comfort and safety during travel. When paired with the caravan’s characteristics, select the ideal air air conditioner and have a fantastic journey.
What are the advantages of inverter air conditioning for RVs over traditional air conditioning?
With the continuous innovation of inverter technology and other air conditioning technologies, the ac advantage is becoming more and more obvious. Compared to traditional air conditioning, the advantages include intelligent regulation of the compressor operating frequency, saving power consumption, and accurate maintenance of the temperature stability of the small space, technological innovation without the need for frequent switching of the compressor. Uniform and comfortable, with a remote control and intelligent connection that is adaptable and modern, as well as cost-effective.
What are the main types of RV air conditioners?
Caravan air conditioners are classified into three types: roof-mounted integrated, split wall-mounted, and split bottom-mounted models. Choosing to install an roof mounted rv ac unit, it is ideal for caravans with unrestricted roof space, high-silence requirements, good cooling effect, high airflow demand, and external power supply. Split wall-mounted and split bottom-mounted air conditioners, in which the outdoor unit is positioned at the back or bottom of the caravan and the inside unit is installed on the caravan’s wall, are ideal for caravans with limited roof space and no external power supply.
Are you still struggling with your car’s air conditioning system?
We specialize in all kinds of rv ac unit, including camper ac unit, trailer ac unit, van ac unit, truck ac unit, boat ac unit, cold chain transport ac unit, medical services ac unit, and other types of ac unit for vehicle and ship, no matter what season, we can bring comfort to your hot summer days, bring warmth to your cold winter days, and eliminate the worries of your journey, energy-saving, comfortable, beautiful, economical, and tailor-made durable, high-quality, and reliable air conditioning system for your car.
Gold Medal Service
Focusing on user experience, insisting on the same quality.
Environmental Protection
Taking energy saving and emission reduction as our responsibility, caring for driver’s health.
Unique Technology
Years of experience, unique and leading technology.
Safety certification
Multiple patented technologies, EU safety certification.
Strict quality management
Exquisite manufacturing and testing equipment, world-class quality management system.
Best-selling in the world
Highly adaptable products, exported to the world, widely acclaimed.
